Security Modes

FastGateway offers two mutually exclusive security modes for protecting routes: General and Client mode.

Mode Comparison

Feature	General Mode	Client Mode
IP Filtering	Route-level allowlist	Per-client IPs
API Keys	Route-level keys	Per-client keys
JWT Validation	Supported	Not supported
OIDC Authentication	Supported	Not supported
Granularity	All consumers same rules	Per-consumer rules

General Mode

Applies security policies at the route level:

┌───────┐     ┌────────────────────┐     ┌─────────┐
│Request│ ──▶ │ Route SecurityPolicy│ ──▶ │ Backend │
└───────┘     │ - IP: 10.0.0.0/8   │     └─────────┘
              │ - JWT: required     │
              └────────────────────┘

Best for: Public APIs, internal services with uniform access requirements.

Client Mode

Applies security policies per client attachment:

┌──────────┐     ┌────────────────────┐     ┌─────────┐
│ Client A │ ──▶ │ Attachment Policy  │ ──▶ │         │
│ IP: 1.2.3│     │ - API Key: abc123  │     │  Route  │
└──────────┘     └────────────────────┘     │         │
┌──────────┐     ┌────────────────────┐     │         │
│ Client B │ ──▶ │ Attachment Policy  │ ──▶ │         │
│ IP: 4.5.6│     │ - API Key: xyz789  │     └─────────┘
└──────────┘     └────────────────────┘

Best for: Partner APIs, multi-tenant platforms, differentiated access.

Important Notes

• Modes are mutually exclusive per route
• Cannot mix General and Client security on the same route
• OIDC is only available in General mode
